60mm Splice Sleeves
Created with Pixso. Fiber Optic Fusion 60mm Splice Sleeves Stainless Steel 304
Name
  • Name
  • Name

Fiber Optic Fusion 60mm Splice Sleeves Stainless Steel 304

Brand Name: XXR
Model Number: OFSS-60T
MOQ: 50,000 pcs
Price: Negotiable
Delivery Time: 5-7 days
Payment Terms: T/T, L/C
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
SGS
Name:
Fusion Splice Protection Sleeves
Brand:
XXR
Steel Rod:
1.2MM
Use:
FTTx & FTTH
Model:
FPS-60T
Length:
60MM
Color:
Clear
OD After Shrink:
3.6MM
Used For:
Horizontal Type Optical Closure
Packaging Details:
100 pcs
Supply Ability:
200K pcs/day
Highlight:

Ss304 60mm Splice Sleeves

,

Fiber Optic Fusion 60mm Splice Sleeves

,

1.2mm Fusion Splice Protection Sleeves

Product Description

XXR Premium Fiber Optic Fusion Splice Protection Sleeves



Features:

  • Transparent sleeve for easy detection of splices before shrinking
  • Ease of use and avoid fiber damage during installation
  • Ensuring a good airtight configuration of the splice point against humidity and temperature
  • The strength members are made from grade 304 "full hard" stainless steel and have edges ground before polishing to make them completely burr-free to avoid cracking when shrinking. Even in coastal environments, grade 304 offers better corrosion resistance. Resistant to thermal shock, no cracks dripping or flowing
  • A hot-melt adhesive tube made of polyolefin-vinyl acetate copolymer is bonded to the optical fiber and a heat-shrink outer tube to effectively encapsulate the fusion splice.​





Specifications:

Part No. Spec. (mm)

Steel rod

dia.(mm)

Outer tube

L.(mm)

OD after shrinking

(mm)

Inner tube

L.(mm)

ID

(mm)
OFSS-40T 1.5 * 40 1.5 40 3.0 40 ≥1.2
OFSS-45T 1.5 * 45 1.5 45 3.0 45 ≥1.2
OFSS-60T 1.5 * 60 1.5 60 3.0 60 ≥1.2
OFSS-40T 1.2 * 40 1.2 40 2.7 40 ≥1.2
OFSS-45T 1.2 * 45 1.2 45 2.7 45 ≥1.2
OFSS-60T 1.2 * 60 1.2 60 2.7 60 ≥1.2



Physical pictures



Fiber Optic Fusion 60mm Splice Sleeves Stainless Steel 304 0



Fiber Optic Fusion 60mm Splice Sleeves Stainless Steel 304 1



Fiber Optic Fusion 60mm Splice Sleeves Stainless Steel 304 2Fiber Optic Fusion 60mm Splice Sleeves Stainless Steel 304 3
Fiber Optic Fusion 60mm Splice Sleeves Stainless Steel 304 4
